Click to enlarge
free shipping
Item #:
N-60333
Category:
Power Supplies
Availability:
Item is in stock
Packaging:
Retail Packaging
Platform:
Windows
Condition:
New
Brand:
Antec
Your Price: $56.70
Add To Cart

Product Rating

(0 Ratings) Write a Review

General Information

Building on a budget doesn't mean you have to trust your components to an un-reliable no-name brand. That's why Antec took its years of experience and knowledge in building world-class power supplies and made Basiq. The workhorse of the Antec family, Basiq is built with solid quality you have come to expect from Antec products at an unbeatable price. Basiq does the job simply, efficiently and reliably, making Basiq a solid power supply built to satisfy the demands on the entry-level power user or the budget minded system builder.

Technical Information
Power Factor Correction (PFC):Active
Number of Fans:1
Holdup Time:17 ms Full Load
Protection Type:Overload
Protection Type:Short Circuit
Protection Type:Over Voltage
Version Supported:ATX12V

Reliability
MTBF:80000 Hour

Power Description
Input Voltage Type:AC
Input Voltage:110 V AC
Input Voltage:220 V AC
Input Voltage Range:100 V AC to 240 V AC
Number of +12V Rails:2
Output Voltage:3.3 V DC @ 30 A
Output Voltage:5 V DC @ 30 A
Output Voltage:12 V DC @ 18 A
Output Voltage:-12 V DC @ 300 mA
Output Voltage:5 V DC @ 2.50 A
Input Current:6 A @110 V AC/3 A @220 V AC
Frequency:47 Hz to 63 Hz
Output Power:500 W

Interfaces/Ports
Plug/Connector:On/Off Switch
Receptacles:1 x 15-pin Serial ATA
Receptacles:1 x 4-pin ATX12V Motherboard
Receptacles:1 x ATX Motherboard

Physical Characteristics
Form Factor:Internal
Height:3.5"
Width:5.8"
Depth:5.5"
Weight (Approximate):3.70 lb

Miscellaneous
Certifications & Standards:
  • CE
  • UL
  • CB
  • CUL
  • TÜV
  • FCC Class B
    • Green Compliant:Yes
    Green Compliance Certificate/Authority:RoHS
    Green Compliance Certificate/Authority:80 Plus
    Country of Origin:China

    Warranty
    Limited Warranty:3 Year



    Product images may differ from actual product appearance.
    Be the first to review this product. Write a Review
    Shipping Restrictions
    • This item cannot be shipped to PO Boxes.
    • This item can be shipped only within the U.S.


    • UPC: 761345235006
    • Mfr's Part #: BP500U
