D-Link DSS-5E 5 Port 10/100 Desktop Switch - 5 Ports - 5 x RJ-45 - 10/100Base-TX - Desktop
free shipping
Item #:
N-192948
Category:
Wired Networking
Availability:
Item is in stock
Packaging:
Retail Packaging
Platform:
N/A
Condition:
New
Brand:
D-Link
Your Price: $31.60
Add To Cart

Product Rating

(0 Ratings) Write a Review

From the Manufacturer

Thank You

Is the information in this section helpful?

Description

Description

Description

The 5-Port 10/100 Desktop Switch (DSS-5E) when connected to a router lets you network up to four additional devices at speeds up to 200Mbps1 at full-duplex and is compact enough to be placed virtually anywhere in your home.

Great Performance and Value

Expand your wired home network with the D-Link 5-Port 10/100 Desktop Switch (DSS-5E). This Desktop Switch it's virtually anywhere because of its compact size and can also be mounted on a wall or underneath a desk. By connecting the DSS-5E to your router, you can add up to four computers to your home network. A game console, printer, print server, Network-Attached Storage (NAS) or network camera can be added to increase the functionality of your network.

Efficient Networking

This 5-Port 10/100 Desktop Switch receives and forwards traffic seamlessly with its non-blocking wire-speed architecture. Every port simultaneously supports up to 200Mbps of bandwidth, totaling 1Gbps of switching capacity. It minimizes bottlenecks, allowing your network to run smoothly even during the heaviest volume of traffic.

Easy To Install and Use

The DSS-5E requires no configuration and installation is simple. Whether you are connecting the DSS-5E to another switch or a computer, there is never a need for crossover cables with Auto MDI/MDI-X support. Additionally, the Desktop Switch auto-senses if the network device it is connected to is running at 10Mbps or 100Mbps and adjusts accordingly. Equipped with a comprehensive LED display, you can monitor the status and activity of every port at a glance. With outstanding performance, quality, and features packed in a compact sized device, the D-Link 5-Port 10/100 Desktop Switch (DSS-5E) is a great selection for expanding your home network.

What This Product Does

The DSS-5E is a 5-port 10/100Mbps Ethernet switch. By connecting the DSS-5E to your router, you can add up to four computers or other Ethernet-based devices to your home network. Add a print server, Network-Attached Storage (NAS) or network camera and experience the benefits of networking.

All references to speed are for comparison purposes only. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted on the package. See inside package for warranty details. This product is designed for the use in the USA and Canada. Use of this product in other countries might violate local laws.

Features

  • Add More Computers and devices to your network
  • No Software configuration required – just connect it to the network
  • Delivers up to 200Mbps1 throughput per port in full duplex mode

Images

Specification

Specifications
Standards
  • IEEE 802.3 10Base-T Ethernet
  • IEEE 802.3u 100Base-TX Fast Ethernet
  • IEEE 802.3 Nway Auto-negotiation
  • IEEE 802.3x Flow Control
Features
  • 5 10/100BASE-TX Ports
  • MAC Address Table: 2k
  • Switch Fabric: 1.0Gbps
  • Packet Buffer Memory: 49KB Buffer
  • Transmission Method: Store-and-forward
  • RoHS Compliant
Network Data Transfer Rate
  • Ethernet: 10Mbps (Half-duplex)
  • Ethernet: 20Mbps (Full-duplex)
  • Fast Ethernet: 100Mbps (Half-duplex)
  • Fast Ethernet: 200Mbps (Full-duplex)
Packet Filtering/Forwarding Rates
  • Ethernet: 14,880 pps per port
  • Fast Ethernet: 148,800 pps per port
Interface Options
  • RJ-45: 10BASE-T, 100BASE-TX Universal UTP Cable
  • Recognition for Straight-through or Crossover cables
MTBF
  • 1,516,996 hours
LEDs
  • Per unit: Power
  • Per Port: Link/Activity 10/100Mbps
Certifications
  • FCC Class B
  • ICES-003 Class B
  • CE Class B
  • C-Tick Class B
  • cUL
  • CB
Power Consumption
  • Power On (standby):
    • DC Input: 0.3 Watts
    • AC Input: 1.1 Watts
  • Maximum:
    • DC Input: 2.0 Watts
    • AC Input: 3.4 Watts
Power Supply
  • DC 5V/1A
Operating Temperature
  • 32°F to 122°F (0°C ~ 40°C)
Operating Humidity
  • 10% ~ 90% (Non-condensing)
Dimensions
  • Item (W x D x H): 3.8” x 3.1” x 1.1” (97mmx 79mm x 28mm)
  • Packaging (W x D x H): 6.3” x 3.7” x 4.1” (160mm x 95mm x 103mm)
Weight
  • Item: 0.2 lbs (0.09 kg)
  • Packaging: 0.66 lbs (0.30 kg)
Warranty
  • Limited Lifetime2
Minimum System Requirements
  • Devices Supporting 802.3 Ethernet or 802.3u Fast Ethernet
  • Ethernet Cable
  • Ethernet port for Each Computer
Package Contents
  • 5-Port 10/100 Desktop Switch
  • Power Adapter
  • Quick Install Guide

All references to speed are for comparison purposes only. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.

Data Sheet

1 Actual data throughput will vary. Network conditions and environmental factors including volume of network traffic, and network overhead, lower actual data throughput rate.
2 Limited Lifetime Warranty available only in the USA and Canada.

General Information

The 5-Port 10/100 Desktop Switch (DSS-5E) when connected to a router lets you network up to four additional devices at speeds up to 200Mbps1 at full-duplex and is compact enough to be placed virtually anywhere in your home.

Great Performance and Value
Expand your wired home network with the D-Link 5-Port 10/100 Desktop Switch (DSS-5E). This Desktop Switch it's virtually anywhere because of its compact size and can also be mounted on a wall or underneath a desk. By connecting the DSS-5E to your router, you can add up to four computers to your home network. A game console, printer, print server, Network-Attached Storage (NAS) or network camera can be added to increase the functionality of your network.

Interfaces/Ports
Total Number of Network Ports:5
Token Ring Port:No
LRE Port:No
Uplink Port:No
Bypass:No
Modular:No
USB:No
Stack Port:No
Number of Network (RJ-45) Ports:5

Media & Performance
Media Type Supported:Twisted Pair
Ethernet Technology:Fast Ethernet
Network Technology:10/100Base-TX

I/O Expansions
Shared SFP Slot:No

Network & Communication
Layer Supported:2

Reliability
MTBF:1516996 Hour

Power Description
PoE (RJ-45) Port:No
Input Voltage:5 V DC
Power Source:AC Adapter
Redundant Power Supply:No

Physical Characteristics
Form Factor:Desktop
Height:1.1"
Width:3.8"
Depth:3.1"
Weight (Approximate):3.20 oz

Miscellaneous
Package Contents:
  • DSS-5E 5 Port 10/100 Desktop Switch
  • Power Adapter
  • Quick Install Guide
Certifications & Standards:
  • IEEE 802.3u
  • IEEE 802.3
  • IEEE 802.3x
  • FCC Class B
  • ICES-003 Class B
  • CE Class B
  • C-Tick Class B
  • cUL
  • CB
Green Compliant:Yes
Green Compliance Certificate/Authority:RoHS
Green Compliance Certificate/Authority:Energy Star

Warranty
Limited Warranty:Lifetime




Product images may differ from actual product appearance.
Be the first to review this product. Write a Review
Shipping Restrictions
  • This item cannot be shipped to PO Boxes.
  • This item can be shipped only within the U.S.


  • UPC: 790069342424
  • Mfr's Part #: DSS-5E
