Intel Executive DB75EN Desktop Motherboard - Intel B75 Express Chipset - Socket H2 LGA-1155 - 1 Pack - Micro ATX - 1 x Processor Support - 32 GB DDR3 SDRAM Maximum RAM - Serial ATA/300, Serial ATA/600 - CPU Dependent Video - 1 x PCIe x16 Slot - 2 x USB 3.
free shipping
- Item #:
- N-192225
- Category:
- Motherboards
- Availability:
- Item is in stock
- Packaging:
- Retail Packaging
- Platform:
- N/A
- Condition:
- New
- Brand:
- Intel
General Information
Powered by the 3rd generation Intel Core processor family, Intel Desktop Board DB75EN maximizes employee productivity, PC performance, and data security with Intel Small Business Advantage. Based on the latest Intel B75 Express Chipset, Intel Desktop Board DB75EN offers 32 GB memory support using four DIMMS. Peripherals that require parallel, VGA, and PS/2 connectors will find a perfect home on Intel Desktop Board DB75EN that offers legacy connectivity flexibilities. |
Processor & Chipset
| Chipset Manufacturer: | Intel |
| Chipset Model: | B75 Express |
| Total Processor Supported: | 1 |
| Processor Socket: | Socket H2 LGA-1155 |
| Processor Supported: | Core i5 |
| Processor Supported: | Core i7 |
| Processor Supported: | Core i3 |
| 64-bit Processing: | Yes |
Memory
| Number of Memory Slots: | 4 |
| Memory Form Factor: | DIMM |
| Maximum Memory: | 32 GB |
| Memory Standard: | DDR3-1600/PC3-12800 |
| Memory Standard: | DDR3-1333/PC3-10600 |
| Memory Technology: | DDR3 SDRAM |
I/O Controller
| Controller Type: | Serial ATA/300 |
| Controller Type: | Serial ATA/600 |
Video
| Onboard Video: | CPU Dependent Video |
Audio
| Sound Controller Manufacturer: | Realtek |
| Sound Controller Model: | ALC692 |
| Audio Channels: | 7.1 |
Network & Communication
| Gigabit Ethernet: | Yes |
I/O Expansions
| Number of Total Expansion Slots: | 4 |
| Number of PCI Slots: | 2 |
| PCI Express Standard: | PCI Express 2.0 |
| PCI Express Standard: | PCI Express 3.0 |
| Total Number of PCI Express Slots: | 2 |
| Number of PCI Express x1 Slots: | 1 |
| Number of PCI Express x16 Slots: | 1 |
Interfaces/Ports
| Total Number of USB Ports: | 6 |
| Number of USB 2.0 Ports: | 4 |
| Number of USB 3.0 Ports: | 2 |
| Parallel Port: | Yes |
| Audio Line In: | Yes |
| Audio Line Out: | Yes |
| Microphone Port: | Yes |
| VGA: | Yes |
| DVI: | Yes |
| Number of DVI Outputs: | 1 |
| Network (RJ-45): | Yes |
| Number of Network (RJ-45) Ports: | 1 |
| PS/2 Port: | Yes |
| Number of PS/2 Ports: | 1 |
Onboard Interfaces
| Number of SATA Interfaces: | 5 |
| Total Number of Onboard USB Ports: | 6 |
| Number of Onboard USB 2.0 Ports: | 4 |
| Number of Onboard USB 3.0 Ports: | 2 |
| Onboard Serial Header: | Yes |
| Onboard LEDs Header: | Yes |
| Onboard Audio Header: | Yes |
Power Description
| Power Supply Supported: | EPS12V |
Physical Characteristics
| Form Factor: | Micro ATX |
| Width: | 9.6" |
| Depth: | 9.6" |
Product images may differ from actual product appearance.
Be the first to review this product.
Write a Review
Shipping Restrictions
- This item cannot be shipped to PO Boxes.
- This item can be shipped only within the U.S.
- UPC: 735858240536
- Mfr's Part #: BOXDB75EN
